Cement Grinding Mill

Cement Grinding Mill
Cement Grinding Mill Cement Grinding Mill

In addition to cement production industry, this range of cement grinding mill is also suitable for grinding various ores and other grindable materials in building material, metallurgy, chemical, and power generation industries. It supports long term continuous operation, and offers marvelous material adaptability and large size reduction ratio.

Primarily designed for open-circuit grinding, the cement mill is also applicable for use in combination with powder separators to form a closed circuit grinding system. It is compatible with both dry type and wet type grinding, and also supports synchronous grinding and drying.

Uniquely designed with the material-chamber partition board and the grid plate for material level adjustment, our cement grinding mill is provided with increased airflow to improve the grinding condition inside the grinder. In addition, it is available with new type lining plate design, re-adjusted the rotation speed, optimized gear design and bearing bush lubricant. This helps increase the operation stability and service life of the grinding equipment, and also improves the grinding efficiency.

Technical Parameters
Size (diameter*length ) (m) Rotation speed
(r/min)		 Feeding size (mm) Productivity (t/h) Material loading capacity (t) Main motor Main speed reducer Weight (t)
Model Power (kw) Rotation speed (r.p.m) Model Speed ratio
φ2.2×11 20.91 ≤25 15～17 50 TR1512-8 570 740 Zd80 5.6 92
φ2.4×8 20.91 ≤25 14～18 39.5～42 TRQ1512-8 570 740 Zd80-9 5 76.4
φ2.4×9 20.91 ≤25 23～25 (closed-circuit) 50 TR1512-8 570 740 Zd80-9 5 91
φ2.4×10 20.91 ≤25 16～22 50 TR1512-8 570 740 Zd80-9 5 111
φ2.4×11 21 ≤25 19～24 (open circuit)

22～28 (closed-circuit)		 6265 YR710-8/1180 710 740 JDX630 5.6 125
φ2.4×12 21 ≤25 18～20 (open circuit)

21～23 (closed-circuit)		 6365 YR800-8/1180 800 740 MBY710 6.3 127
φ2.4×13 21 ≤25 21～22 (open circuit)

24～26 (closed-circuit)		 6668 YR800-8/1180 800 740 MBY710 6.3 131
φ2.6×10 20.6 ≤25 21～24 64 YR800-8/1180 800 740 JDX710 6.3 140
φ2.6×13 20.6 ≤25 28～31 81 YR1000-8/1180 1000 740 JDX800 6.3 158
φ3.0×9 19.13 ≤25 40～45 85 YR1000-8/1180 1000 740 MBY800 7.1 148
φ3×11 18.92 ≤25 44～47 95 YR1250-8/1430 1250 740 JDX900 7.1 177
φ3×12 18.92 ≤25 48～52 103 YR1250-8/1430 1250 740 JDX900 7.1 182
φ3×13 18.92 ≤25 39～45 116max YR1400-8/1430 1400 740 JDX900 7.1 200.7
φ3.2×11 18.3 ≤25 45～48 112max YR1600-8/1430 1400 740 JDX900 7.15 213.6
φ3.2×13 18.7 ≤25 50～55 133max YR1600-8/1430 1600 740 JDX1000 7.15 237
φ3.4×11 18 ≤25 45～55 120max YR1600-8/1430 1600 740 JDX1000 230
φ3.5×13 17 ≤25 60～65 156max YR2000-8/1730 2000 740 TS130-A-F1 257.6
φ3.8×13
(main bearing type)		 17 ≤25 65～70 190 YR2500-8/1730 2500 740 JS130-C-F1 316
φ3.8×13
(slide shoe bearing support; edge driving)		 17 ≤25 65～70 185 YR2500-8/1730 2500 740 DMG22/2500 313
φ4×13 16.3 ≤25 78～80 191 YRKK900-80 2800 745 JS140-A 348
φ4.2×11
(main bearing type)		 15.8 ≤25 100～110 182～190 YR2800-8/17830 2800 740 JS140-A-F1D 350
φ4.2×13
(main bearing type)		 15.2 ≤25 120～130 245 YRKK1000-8 3350 740 MFY355-A 390
φ4.2×13
(slide shoe bearing support; central driving)		 15.2 ≤25 110～120 230 YRKK1000-8 3350 740 MFY355-A 380
φ4.6×14 15 ≤25 100～115 285 YR1000-8 4200 740 J3160-C 485

Note: Above parameters are provided for your reference only. Specific ones will be provided in purchasing contracts.
